珠海派特爾 - 管系列
首頁 - 產(chǎn)品中心 - 珠海派特爾
| 代碼 | 內(nèi)徑 | 外徑 | 管壁厚 | 長度 | 重量 | |||||
| mm | Inch | mm | Inch | mm | Inch | mm | Inch | g/m | lb/ft | |
| HS1075 | 7.5 | 0.30 | 10.0 | 0.39 | 1.20 | 0.047 | 9.5 | 0.347 | 36 | 0.024 |
| HS1295 | 9.5 | 0.37 | 12 | 0.47 | 1.20 | 0.047 | 11.5 | 0.452 | 44 | 0.029 |
| HS1613 | 13 | 0.51 | 16 | 0.62 | 1.40 | 0.055 | 15 | 0.590 | 72 | 0.048 |
| HS1815 | 15 | 0.59 | 18.3 | 0.72 | 1.60 | 0.062 | 17.5 | 0.688 | 82 | 0.054 |
| HS2520 | 20 | 0.79 | 25.4 | 1.0 | 2.0 | 0.078 | 22.5 | 0.885 | 145 | 0.098 |
| HS3025 | 25 | 0.98 | 29.5 | 1.16 | 2.2 | 0.086 | 28 | 1.102 | 178 | 0.118 |
| HS3530 | 30 | 1.18 | 35.4 | 1.39 | 2.5 | 0.098 | 30 | 1.101 | 291 | 0.194 |
| HS5040 | 40 | 1.57 | 50 | 1.96 | 4.5 | 0.177 | 28 | 1.102 | 600 | 0.401 |
| HS6050 | 50 | 1.91 | 60 | 2.36 | 6.0 | 0.236 | 28 | 1.102 | 730 | 0.487 |
| HS7060 | 60 | 2.36 | 70 | 2.75 | 6.0 | 0.226 | 28 | 1.102 | 1100 | 0.735 |
| HS9280 | 80 | 3.15 | 92 | 3.62 | 6.5 | 0.255 | 40 | 1.574 | 750 | 0.501 |
| HS112100 | 100 | 3.94 | 112 | 4.40 | 6.5 | 0.255 | 40 | 1.574 | 2100 | 1.403 |
